دیتاشیت LM2940CSX-9.0/NOPB
مشخصات دیتاشیت
| نام دیتاشیت | LM2940(-N, C) |
|---|---|
| حجم فایل | 2497.017 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 35 |
دانلود دیتاشیت LM2940(-N, C) |
LM2940(-N, C) Datasheet |
|---|
مشخصات
- Control Features: -
- Base Part Number: LM2940
- Package / Case: TO-263-4, D²Pak (3 Leads + Tab), TO-263AA
- Current - Supply (Max): 15mA
- Part Status: Obsolete
- Current - Output: 1A
- PSRR: 64dB (120Hz)
- Series: -
- Voltage - Output (Min/Fixed): 9V
- Mounting Type: Surface Mount
- Number of Regulators: 1
- Current - Quiescent (Iq): 10mA
- Output Configuration: Positive
- Voltage Dropout (Max): 0.8V @ 1A
- Operating Temperature: 0°C ~ 125°C
- Supplier Device Package: DDPAK/TO-263-3
- Protection Features: Over Current, Over Temperature, Reverse Polarity, Short Circuit
- Manufacturer: Texas Instruments
- Voltage - Input (Max): 26V
- Output Type: Fixed
- Packaging: Tape & Reel (TR)
- Voltage - Output (Max): -
- detail: Linear Voltage Regulator IC 1 Output 1A DDPAK/TO-263-3
