TL064 Datasheet

TL064

Datasheet specifications

Datasheet's name TL064
File size 773.322 KB
File type pdf
Number of pages 17

Download Datasheet TL064

Download Datasheet

Other documentations

TL062CP 52 pages

Technical specifications

  • RoHS: true
  • Category: Operational Amplifier/Comparator/FET InputAmplifiers
  • Datasheet: Texas Instruments TL064ACN
  • Number of Circuits: 4
  • Operating Temperature: 0°C~+70°C
  • Current - Input Bias(Ib): 30pA
  • Gain Bandwidth Product(GBP): 1MHz
  • Voltage - Input Offset(Vos): 3mV
  • Package: PDIP-14
  • Manufacturer: Texas Instruments
  • Series: -
  • Packaging: Tube
  • Part Status: Obsolete
  • Amplifier Type: J-FET
  • Output Type: -
  • Slew Rate: 3.5V/µs
  • Gain Bandwidth Product: 1MHz
  • Current - Input Bias: 30pA
  • Voltage - Input Offset: 3mV
  • Current - Supply: 200µA
  • Current - Output / Channel: 20mA
  • Voltage - Supply, Single/Dual (±): 6V ~ 36V, ±3V ~ 18V
  • Mounting Type: Through Hole
  • Package / Case: 14-DIP (0.300", 7.62mm)
  • Supplier Device Package: 14-DIP
  • Base Part Number: TL064
  • detail: J-FET Amplifier 4 Circuit 14-DIP
