Analog Signal Chain Guide Datasheet

Analog Signal Chain Guide

Datasheet specifications

Datasheet's name Analog Signal Chain Guide
File size 1059.19 KB
File type pdf
Number of pages 11

Download Datasheet Analog Signal Chain Guide

Download Datasheet

Other documentations

REF5020,25,30,40,45,50 Datasheet 40 pages

REF5020AID 39 pages

Technical specifications

  • RoHS: true
  • Category: Power Supply Chip/Voltage References
  • Datasheet: Texas Instruments REF5020AIDR
  • Tolerance: ±0.1%
  • Output Type: Fixed
  • Input Voltage: 2.7V~18V
  • Output Current: 10mA
  • Output Voltage: 2.048V
  • Reference Type: series connection
  • Supply Current: 1.2mA
  • Noise - 10Hz to 10kHz: -
  • Operating Temperature: -40°C~+125°C@(Ta)
  • Noise - 1/10Hz to 10Hz: 3uVp-p
  • Temperature Coefficient: 8ppm/°C
  • Package: SOP-8
  • Manufacturer: Texas Instruments
  • Mounting Type: Surface Mount
  • Part Status: Active
  • Base Part Number: REF502
  • Voltage - Output (Min/Fixed): 2.048V
  • Package / Case: 8-SOIC (0.154", 3.90mm Width)
  • Current - Output: 10mA
  • Packaging: Tube
  • Supplier Device Package: 8-SOIC
  • Series: -
  • Current - Supply: 1.2mA
  • Noise - 0.1Hz to 10Hz: 3µVp-p
  • Voltage - Input: 2.7V ~ 18V
  • detail: Series Voltage Reference IC ±0.1% 8-SOIC
