دیتاشیت CD74HCT688E

CD54,74HC(T)688

مشخصات دیتاشیت

نام دیتاشیت CD54,74HC(T)688
حجم فایل 1344.78 کیلوبایت
نوع فایل pdf
تعداد صفحات 20

دانلود دیتاشیت CD54,74HC(T)688

CD54,74HC(T)688 Datasheet

مشخصات

  • RoHS: true
  • Output: Active Low
  • Category: Logic ICs/Digital Comparators
  • Datasheet: Texas Instruments CD74HCT688E
  • Sink Current: 4mA
  • Source Current: 4mA
  • Supply Voltage: 4.5V~5.5V
  • Output Function: A=B
  • Quiescent Current: 8uA
  • Number of Channels: 8
  • Operating Temperature: -55°C~+125°C
  • Maximum Propagation Delay: 34ns@4.5V,50pF
  • Package: PDIP-20
  • Manufacturer: Texas Instruments
  • Voltage - Supply: 4.5V ~ 5.5V
  • Package / Case: 20-DIP (0.300", 7.62mm)
  • Packaging: Tube
  • Type: Identity Comparator
  • Base Part Number: 74HCT688
  • Part Status: Active
  • Current - Output High, Low: 4mA, 4mA
  • Series: 74HCT
  • Number of Bits: 8
  • Supplier Device Package: 20-PDIP
  • Mounting Type: Through Hole
  • Current - Quiescent (Iq): 8µA
  • Max Propagation Delay @ V, Max CL: 34ns @ 4.5V, 50pF
  • detail: Magnitude Comparator Bit Active Low Output A=B 20-PDIP
