دیتاشیت TPS61085PWR
مشخصات دیتاشیت
| نام دیتاشیت |
TPS61085
|
| حجم فایل |
1478.752
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
30
|
مشخصات
-
RoHS:
true
-
Category:
Power Supply Chip/DC-DC Converters
-
Function:
boost converterType
-
Topology:
Boost
-
Datasheet:
Texas Instruments TPS61085PWR
-
Output Type:
Adjustable
-
Input Voltage:
2.3V~6V
-
Output Voltage:
2.8V~18.5V
-
Number of Outputs:
1
-
Switching Frequency:
650kHz;1.2MHz
-
Output Current (Max):
2A
-
Operating Temperature:
-40°C~+85°C@(TA)
-
Synchronous Rectification:
NO
-
Package:
TSSOP-8
-
Manufacturer:
Texas Instruments
-
Current - Output:
2A (Switch)
-
Voltage - Input (Max):
6V
-
Frequency - Switching:
650kHz, 1.2MHz
-
Part Status:
Active
-
Base Part Number:
TPS610
-
Voltage - Output (Min/Fixed):
2.8V
-
Package / Case:
8-TSSOP (0.173", 4.40mm Width)
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Synchronous Rectifier:
No
-
Output Configuration:
Positive
-
Voltage - Output (Max):
18.5V
-
Mounting Type:
Surface Mount
-
Supplier Device Package:
8-TSSOP
-
Voltage - Input (Min):
2.3V
-
detail:
Boost Switching Regulator IC Positive Adjustable 2.8V 1 Output 2A (Switch) 8-TSSOP (0.173", 4.40mm Width)
