UCC28089DR دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت UCC28089DR	دانلود دیتاشیت

UCC28089 25 pages

RoHS: true
Category: Power Supply Chip/AC-DC Controllers & Regulators
Topology: Push-pull
Datasheet: Texas Instruments UCC28089DR
Duty Cycle: 50%
Supply Voltage: 8.5V~14V
Switching Frequency: 1MHz
Operating Temperature: -40°C~+105°C@(TA)
Package: SOP-8
Manufacturer: Texas Instruments
Part Status: Active
Package / Case: 8-SOIC (0.154", 3.90mm Width)
Packaging: Cut Tape (CT)
Frequency - Switching: Up to 1MHz
Supplier Device Package: 8-SOIC
Number of Outputs: 2
Serial Interfaces: -
Synchronous Rectifier: No
Function: Step-Up/Step-Down
Clock Sync: Yes
Mounting Type: Surface Mount
Output Configuration: Positive, Isolation Capable
Base Part Number: UCC280
Series: -
Output Type: Transistor Driver
Control Features: Dead Time Control, Frequency Control
Output Phases: 1
Duty Cycle (Max): 50%
Voltage - Supply (Vcc/Vdd): 8.5V ~ 14V
detail: Push-Pull Regulator Positive, Isolation Capable Output Step-Up/Step-Down DC-DC Controller IC 8-SOIC
