LP311P دیتاشیت

LP311P

مشخصات دیتاشیت

نام دیتاشیت LP311P
حجم فایل 98.557 کیلوبایت
نوع فایل pdf
تعداد صفحات 14

دانلود دیتاشیت LP311P

دانلود دیتاشیت

سایر مستندات

LP211, LP311 13 pages

مشخصات فنی

  • RoHS: true
  • Category: Operational Amplifier/Comparator/Comparators
  • Datasheet: Texas Instruments LP311P
  • Output Type: Push Pull
  • Supply Voltage: 3.5V~30V;1.75V~15V
  • Number of Elements: -
  • Operating Temperature: 0°C~+70°C
  • Input Bias Current (Ib): 0.1uA
  • Input Offset Voltage (Vos): 7.5mV
  • Input Hysteresis Voltage (Vhys): -
  • Common Mode Rejection Ratio (CMRR): 80dB
  • Package: PDIP-8
  • Manufacturer: Texas Instruments
  • Package / Case: 8-DIP (0.300", 7.62mm)
  • Propagation Delay (Max): -
  • Current - Quiescent (Max): 300µA
  • Voltage - Input Offset (Max): 7.5mV @ ±15V
  • Part Status: Active
  • Current - Output (Typ): -
  • Current - Input Bias (Max): 0.1µA @ ±15V
  • Packaging: Tube
  • Type: Differential
  • CMRR, PSRR (Typ): -
  • Voltage - Supply, Single/Dual (±): 3.5V ~ 30V, ±1.75V ~ 15V
  • Series: -
  • Base Part Number: LP311
  • Supplier Device Package: 8-PDIP
  • Mounting Type: Through Hole
  • Hysteresis: -
  • detail: Comparator Differential Open-Collector, Open-Emitter 8-PDIP
