TPS71501MDCKREP دیتاشیت

TPS71501MDCKREP

مشخصات دیتاشیت

نام دیتاشیت TPS71501MDCKREP
حجم فایل 72.287 کیلوبایت
نوع فایل pdf
تعداد صفحات 15

مشاهده دیتاشیت TPS71501MDCKREP

دانلود دیتاشیت

سایر مستندات

TPS71501-EP 15 pages

مشخصات فنی

  • RoHS: true
  • Category: Power Supply Chip/Linear Voltage Regulators (LDO)
  • Datasheet: Texas Instruments TPS71501MDCKREP
  • Output Type: Adjustable
  • Output Current: 50mA
  • Output Voltage: 1.2V~15V
  • Dropout Voltage: 0.23V@(500mA)
  • Output Polarity: positive
  • Number of Outputs: 1
  • Maximum Input Voltage: 24V
  • Operating Temperature: -55°C~+125°C
  • Quiescent Current (Ground Current): 4.2uA
  • Package: SC-70-5
  • Manufacturer: Texas Instruments
  • Current - Supply (Max): 5.8µA
  • Output Configuration: Positive
  • Package / Case: 5-TSSOP, SC-70-5, SOT-353
  • Packaging: Cut Tape (CT)
  • Protection Features: Over Temperature, Reverse Polarity
  • Number of Regulators: 1
  • Part Status: Active
  • Current - Quiescent (Iq): 4.2µA
  • Supplier Device Package: SC-70-5
  • Voltage - Input (Max): 24V
  • Voltage - Output (Min/Fixed): 1.2V
  • Mounting Type: Surface Mount
  • PSRR: 55dB ~ 52dB (120Hz)
  • Base Part Number: TPS715
  • Series: -
  • Control Features: Enable, Power Good
  • Voltage - Output (Max): 15V
  • Voltage Dropout (Max): 0.23V @ 500mA
  • Current - Output: 50mA
  • detail: Linear Voltage Regulator IC 1 Output 50mA SC-70-5
