ADS1014IDGST دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | ADS1014IDGST |
|---|---|
| حجم فایل | 94.53 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 48 |
دانلود دیتاشیت ADS1014IDGST |
دانلود دیتاشیت |
|---|
سایر مستندات
ADS1013 - ADS1015 Datasheet 50 pages
مشخصات فنی
- RoHS: true
- Category: ADC/DAC/Data Conversion/Analog To Digital Converters (ADCs)
- Datasheet: Texas Instruments ADS1014IDGST
- Package: MSOP-10
- Manufacturer: Texas Instruments
- Architecture: Sigma-Delta
- Input Type: Differential, Single Ended
- Series: -
- Ratio - S/H:ADC: -
- Operating Temperature: -40°C ~ 125°C
- Packaging: Cut Tape (CT)
- Data Interface: I²C
- Reference Type: Internal
- Part Status: Active
- Supplier Device Package: 10-VSSOP
- Number of A/D Converters: 1
- Sampling Rate (Per Second): 3.3k
- Configuration: MUX-PGA-ADC
- Package / Case: 10-TFSOP, 10-MSOP (0.118", 3.00mm Width)
- Mounting Type: Surface Mount
- Base Part Number: ADS1014
- Features: PGA, Selectable Address
- Number of Bits: 12
- Number of Inputs: 1, 2
- Voltage - Supply, Analog: 2V ~ 5.5V
- Voltage - Supply, Digital: 2V ~ 5.5V
- detail: 12 Bit Analog to Digital Converter 1, 2 Input 1 Sigma-Delta 10-VSSOP
