TPS7133QDR دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
TPS7133QDR
|
|
حجم فایل
|
93.278
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
39
|
مشخصات فنی
-
RoHS:
true
-
Category:
Power Supply Chip/Linear Voltage Regulators (LDO)
-
Datasheet:
Texas Instruments TPS7133QDR
-
Output Type:
Fixed
-
Output Current:
500mA
-
Output Voltage:
3.3V~3.3V
-
Dropout Voltage:
400mV@(500mA)
-
Output Polarity:
Positive
-
Number of Outputs:
1
-
Maximum Input Voltage:
10V
-
Power Supply Rejection Ratio (PSRR):
59dB@(120Hz)
-
Package:
SOIC-8
-
Manufacturer:
Texas Instruments
-
Current - Supply (Max):
460µA
-
Output Configuration:
Positive
-
Package / Case:
8-SOIC (0.154", 3.90mm Width)
-
Packaging:
Cut Tape (CT)
-
Protection Features:
Over Temperature, Reverse Polarity
-
Number of Regulators:
1
-
Part Status:
Active
-
Current - Quiescent (Iq):
350µA
-
Operating Temperature:
-40°C ~ 125°C
-
Supplier Device Package:
8-SOIC
-
Voltage - Input (Max):
10V
-
Voltage - Output (Min/Fixed):
3.3V
-
Mounting Type:
Surface Mount
-
PSRR:
59dB ~ 54dB (120Hz)
-
Base Part Number:
TPS713
-
Series:
-
-
Control Features:
Enable, Power Good
-
Voltage - Output (Max):
-
-
Voltage Dropout (Max):
0.4V @ 500mA
-
Current - Output:
500mA
-
detail:
Linear Voltage Regulator IC 1 Output 500mA 8-SOIC
