VNQ5E160K-E دیتاشیت

VNQ5E160K-E

مشخصات دیتاشیت

نام دیتاشیت VNQ5E160K-E
حجم فایل 547.241 کیلوبایت
نوع فایل pdf
تعداد صفحات 34

مشاهده دیتاشیت VNQ5E160K-E

دانلود دیتاشیت

سایر مستندات

ST VNQ5E160KTR-E 34 pages

مشخصات فنی

  • RoHS: true
  • Category: Power Supply Chip/Power Distribution Switches
  • Datasheet: STMicroelectronics VNQ5E160KTR-E
  • Input Voltage: 4.5V~28V
  • Output Current: 7A
  • Number of Outputs: 4
  • Resistor On-State: 160mΩ
  • Operating Temperature -: -40°C~+150°C
  • Package: PowerSSO-24
  • Manufacturer: STMicroelectronics
  • Series: VIPower™
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Switch Type: General Purpose
  • Ratio - Input:Output: 1:1
  • Output Configuration: High Side
  • Output Type: N-Channel
  • Interface: On/Off
  • Voltage - Load: 4.5V ~ 28V
  • Voltage - Supply (Vcc/Vdd): Not Required
  • Current - Output (Max): 7A
  • Rds On (Typ): 160mOhm (Max)
  • Input Type: Non-Inverting
  • Features: Auto Restart
  • Fault Protection: Current Limiting (Fixed), Open Load Detect, Over Temperature, Over Voltage
  • Operating Temperature: -40°C ~ 150°C (TJ)
  • Mounting Type: Surface Mount
  • Supplier Device Package: PowerSSO-24™
  • Package / Case: 24-SOP (0.295", 7.50mm Width) Exposed Pad
  • Base Part Number: VNQ5E160
  • detail: Power Switch/Driver 1:1 N-Channel 7A PowerSSO-24™
