L6375STR دیتاشیت

L6375STR

مشخصات دیتاشیت

نام دیتاشیت L6375STR
حجم فایل 58.897 کیلوبایت
نوع فایل pdf
تعداد صفحات 20

مشاهده دیتاشیت L6375STR

دانلود دیتاشیت

سایر مستندات

L6375S 20 pages

مشخصات فنی

  • RoHS: true
  • Category: Power Supply Chip/Power Distribution Switches
  • Datasheet: STMicroelectronics L6375STR
  • Input Voltage: 8V~35V
  • Output Current: 500mA
  • Number of Outputs: 1
  • Operating Temperature -: -25°C~+125°C
  • Package: SOP-8
  • Manufacturer: STMicroelectronics
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Switch Type: General Purpose
  • Ratio - Input:Output: 1:1
  • Output Configuration: High Side
  • Output Type: N-Channel
  • Interface: On/Off
  • Voltage - Load: 8V ~ 35V
  • Voltage - Supply (Vcc/Vdd): Not Required
  • Current - Output (Max): 500mA
  • Rds On (Typ): -
  • Input Type: Non-Inverting
  • Features: Status Flag
  • Fault Protection: Current Limiting (Fixed), Open Load Detect, Over Temperature, UVLO
  • Operating Temperature: -25°C ~ 125°C (TJ)
  • Mounting Type: Surface Mount
  • Supplier Device Package: 8-SOIC
  • Package / Case: 8-SOIC (0.154", 3.90mm Width)
  • Base Part Number: L6375
  • detail: Power Switch/Driver 1:1 N-Channel 500mA 8-SOIC
