دیتاشیت TLC5941QPWPRQ1
مشخصات دیتاشیت
| نام دیتاشیت | TLC5941-Q1 Datasheet |
|---|---|
| حجم فایل | 1880.018 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 33 |
دانلود دیتاشیت TLC5941-Q1 Datasheet |
TLC5941-Q1 Datasheet Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Nixie Tube Driver/LED Driver/LED Drivers
- Datasheet: Texas Instruments TLC5941QPWPRQ1
- Package: HTSSOP-28-EP
- Manufacturer: Texas Instruments
- Internal Switch(s): Yes
- Voltage - Output: 17V
- Voltage - Supply (Max): 5.5V
- Part Status: Active
- Applications: Backlight, Signage
- Voltage - Supply (Min): 3V
- Package / Case: 28-PowerTSSOP (0.173", 4.40mm Width)
- Frequency: -
- Packaging: Digi-Reel®
- Type: Linear
- Dimming: -
- Topology: Shift Register
- Series: Automotive, AEC-Q100
- Base Part Number: TLC594
- Operating Temperature: -40°C ~ 125°C (TJ)
- Supplier Device Package: 28-HTSSOP
- Mounting Type: Surface Mount
- Number of Outputs: 16
- Current - Output / Channel: 60mA
- detail: LED Driver IC 16 Output Linear Shift Register Dimming 60mA 28-HTSSOP
