دیتاشیت LM2930T-5.0/NOPB
مشخصات دیتاشیت
| نام دیتاشیت |
LM2930
|
| حجم فایل |
1262.312
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
13
|
مشخصات
-
RoHS:
true
-
Category:
Power Supply Chip/Linear Voltage Regulators (LDO)
-
Datasheet:
Texas Instruments LM2930T-5.0/NOPB
-
Output Current:
150mA
-
Output Voltage:
5V
-
Dropout Voltage:
0.6V@(150mA)
-
Output Polarity:
positive
-
Number of Outputs:
1
-
Maximum Input Voltage:
26V
-
Operating Temperature:
-40°C~+85°C
-
Quiescent Current (Ground Current):
7mA
-
Power Supply Rejection Ratio (PSRR):
56dB@(120Hz)
-
Package:
TO-220
-
Manufacturer:
Texas Instruments
-
Control Features:
-
-
Base Part Number:
LM2930
-
Package / Case:
TO-220-3
-
Current - Supply (Max):
40mA
-
Part Status:
Obsolete
-
Current - Output:
150mA
-
PSRR:
56dB (120Hz)
-
Series:
-
-
Voltage - Output (Min/Fixed):
5V
-
Mounting Type:
Through Hole
-
Number of Regulators:
1
-
Current - Quiescent (Iq):
7mA
-
Output Configuration:
Positive
-
Voltage Dropout (Max):
0.6V @ 150mA
-
Supplier Device Package:
TO-220-3
-
Protection Features:
Load Dump, Mirror-Image Insertion, Over Temperature, Reverse Polarity, Short Circuit
-
Voltage - Input (Max):
26V
-
Output Type:
Fixed
-
Packaging:
Tube
-
Voltage - Output (Max):
-
-
detail:
Linear Voltage Regulator IC 1 Output 150mA TO-220-3
