CSD95480RWJ Datasheet دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت CSD95480RWJ Datasheet	دانلود دیتاشیت

RoHS: true
Category: Power Supply Chip/DC-DC Converters
Function: -
Topology: Step-down
Datasheet: Texas Instruments CSD95480RWJ
Input Voltage: 4.5V~16V
Output Voltage: 5.5V
Number of Outputs: 1
Switching Frequency: 1.25MHz
Output Current (Max): 70A
Operating Temperature: -40°C~+125°C@(TJ)
Synchronous Rectification: Yes
Package: VQFN-CLIP-41-EP(5x6)
Manufacturer: Texas Instruments
Current - Peak Output: 90A
Features: Bootstrap Circuit
Fault Protection: Shoot-Through
Current - Output / Channel: 70A
Rds On (Typ): -
Technology: Power MOSFET
Output Configuration: Half Bridge
Load Type: Inductive, Capacitive
Series: NexFET™
Packaging: Cut Tape (CT)
Interface: PWM
Package / Case: 41-PowerTFQFN
Voltage - Load: 4.5V ~ 16V
Part Status: Active
Base Part Number: CSD9548
Supplier Device Package: 41-VQFN-CLIP (5x6)
Mounting Type: Surface Mount
Voltage - Supply: 4.5V ~ 5.5V
Applications: Synchronous Buck Converters
detail: Half Bridge Driver Synchronous Buck Converters Power MOSFET 41-VQFN-CLIP (5x6)
