ISO7331CDWR دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | ISO7331CDWR |
|---|---|
| حجم فایل | 111.063 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 30 |
دانلود دیتاشیت ISO7331CDWR |
دانلود دیتاشیت |
|---|
سایر مستندات
ISO7330(F)C, ISO7331(F)C 30 pages
مشخصات فنی
- RoHS: true
- Category: Communication Interface Chip/UART/485/232/Digital Isolators
- Data Rate: 25Mbps
- Datasheet: Texas Instruments ISO7331CDWR
- Applications: General-purpose
- Supply Voltage: 3V~5.5V
- Forward Channel: 2
- Reverse channel: 1
- Number of Channels: 3
- Isolation Technology: 电容隔离
- Operating Temperature: -40°C~+125°C
- Voltage Isolation or Not: Without voltage isolation
- Package: SOP-16-300mil
- Manufacturer: Texas Instruments
- Propagation Delay tpLH / tpHL (Max): 58ns, 58ns
- Channel Type: Unidirectional
- Technology: Capacitive Coupling
- Package / Case: 16-SOIC (0.295", 7.50mm Width)
- Packaging: Cut Tape (CT)
- Type: General Purpose
- Part Status: Active
- Inputs - Side 1/Side 2: 2/1
- Supplier Device Package: 16-SOIC
- Common Mode Transient Immunity (Min): 25kV/µs
- Isolated Power: No
- Mounting Type: Surface Mount
- Base Part Number: ISO733
- Rise / Fall Time (Typ): 3ns, 2ns
- Series: -
- Voltage - Isolation: 3000Vrms
- Pulse Width Distortion (Max): 4ns
- Voltage - Supply: 3V ~ 5.5V
- detail: General Purpose Digital Isolator 3000Vrms 3 Channel 25Mbps 25kV/µs CMTI 16-SOIC (0.295", 7.50mm Width)
