ADC120 Datasheet

مشخصات دیتاشیت

نام دیتاشیت ADC120 Datasheet
حجم فایل 501.421 کیلوبایت
نوع فایل pdf
تعداد صفحات 15

مشاهده دیتاشیت ADC120 Datasheet

دانلود دیتاشیت

سایر مستندات

ADC120IPT 15 pages

مشخصات فنی

  • RoHS: true
  • Category: ADC/DAC/Data Conversion/Analog To Digital Converters (ADCs)
  • Datasheet: STMicroelectronics ADC120IPT
  • Interface: SPI
  • resolution: 12Bit
  • Supply Voltage: 2.7V~3.6V
  • number of channels: 8
  • sampling frequency: 1MHz
  • Operating Temperature: -40°C~+125°C
  • Package: TSSOP-16
  • Manufacturer: STMicroelectronics
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Number of Bits: 12
  • Sampling Rate (Per Second): 1M
  • Number of Inputs: 8
  • Input Type: Single Ended
  • Data Interface: SPI
  • Configuration: MUX-S/H-ADC
  • Ratio - S/H:ADC: 1:1
  • Number of A/D Converters: 1
  • Architecture: SAR
  • Reference Type: -
  • Voltage - Supply, Analog: 2.7V ~ 3.6V
  • Voltage - Supply, Digital: 2.7V ~ 3.6V
  • Features: -
  • Package / Case: 16-TSSOP (0.173", 4.40mm Width)
  • Supplier Device Package: 16-TSSOP
  • Mounting Type: Surface Mount
  • detail: 12 Bit Analog to Digital Converter 8 Input 1 SAR 16-TSSOP
