VNH5019ATR-E دیتاشیت

VNH5019ATR-E

مشخصات دیتاشیت

نام دیتاشیت VNH5019ATR-E
حجم فایل 96.405 کیلوبایت
نوع فایل pdf
تعداد صفحات 38

دانلود دیتاشیت VNH5019ATR-E

دانلود دیتاشیت

سایر مستندات

VNH5019A-E 38 pages

مشخصات فنی

  • RoHS: true
  • Type: Brush DC Motor
  • Category: Power Supply Chip/Motor Driver ICs
  • Datasheet: STMicroelectronics VNH5019ATR-E
  • Interface: Parallel;PWM
  • Output Current: 30A
  • Supply Voltage: 5.5V~24V
  • Operating Temperature: -40°C~+150°C@(Tj)
  • Package: MultiPowerSO-30
  • Manufacturer: STMicroelectronics
  • Series: ECOPACK®, VIPower™
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Motor Type - Stepper: -
  • Motor Type - AC, DC: Brushed DC
  • Function: Driver - Fully Integrated, Control and Power Stage
  • Output Configuration: Half Bridge (2)
  • Technology: Power MOSFET
  • Step Resolution: -
  • Applications: Automotive
  • Current - Output: 30A
  • Voltage - Supply: 5.5V ~ 24V
  • Voltage - Load: 5.5V ~ 24V
  • Mounting Type: Surface Mount
  • Package / Case: 30-PowerSOP (0.630", 16.00mm Width)
  • Supplier Device Package: MultiPowerSO-30
  • Base Part Number: VNH5019
  • detail: Motor Driver Power MOSFET Parallel, PWM MultiPowerSO-30
