دیتاشیت L78L06ABZ
مشخصات دیتاشیت
| نام دیتاشیت |
L78L06ABZ
|
| حجم فایل |
50.62
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
45
|
مشخصات فنی
-
RoHS:
true
-
Category:
Power Supply Chip/Linear Voltage Regulators (LDO)
-
Datasheet:
STMicroelectronics L78L06ABZ
-
Output Current:
100mA
-
Output Voltage:
6V
-
Output Polarity:
positive
-
Number of Outputs:
1
-
Maximum Input Voltage:
35V
-
Operating Temperature:
-40°C~+125°C
-
Quiescent Current (Ground Current):
5.5mA
-
Power Supply Rejection Ratio (PSRR):
46dB@(120Hz)
-
Package:
TO-92
-
Manufacturer:
STMicroelectronics
-
Series:
-
-
Packaging:
Bulk
-
Part Status:
Active
-
Output Configuration:
Positive
-
Output Type:
Fixed
-
Number of Regulators:
1
-
Voltage - Input (Max):
30V
-
Voltage - Output (Min/Fixed):
6V
-
Voltage - Output (Max):
-
-
Voltage Dropout (Max):
-
-
Current - Output:
100mA
-
Current - Quiescent (Iq):
5.5mA
-
Current - Supply (Max):
6mA
-
PSRR:
46dB (120Hz)
-
Control Features:
-
-
Protection Features:
Over Current, Over Temperature, Short Circuit
-
Mounting Type:
Through Hole
-
Package / Case:
TO-226-3, TO-92-3 (TO-226AA)
-
Supplier Device Package:
TO-92-3
-
Base Part Number:
L78L06
-
detail:
Linear Voltage Regulator IC 1 Output 100mA TO-92-3
