CSD88584Q5DC Datasheet دیتاشیت

CSD88584Q5DC Datasheet

مشخصات دیتاشیت

نام دیتاشیت CSD88584Q5DC Datasheet
حجم فایل 729.307 کیلوبایت
نوع فایل pdf
تعداد صفحات 25

مشاهده دیتاشیت CSD88584Q5DC Datasheet

دانلود دیتاشیت

سایر مستندات

CSD88584Q5DCT 25 pages

مشخصات فنی

  • RoHS: true
  • Category: Triode/MOS Tube/Transistor/MOSFETs
  • Datasheet: Texas Instruments CSD88584Q5DCT
  • Package: SON-22(6x5)
  • Manufacturer: Texas Instruments
  • Drain to Source Voltage (Vdss): 40V
  • Power - Max: 12W
  • Rds On (Max) @ Id, Vgs: 0.95mOhm @ 30A, 10V
  • FET Type: 2 N-Channel (Half Bridge)
  • Part Status: Active
  • Current - Continuous Drain (Id) @ 25°C: -
  • FET Feature: Standard
  • Input Capacitance (Ciss) (Max) @ Vds: 12400pF @ 20V
  • Operating Temperature: -55°C ~ 150°C (TJ)
  • Packaging: Cut Tape (CT)
  • Package / Case: 22-PowerTFDFN
  • Series: NexFET™
  • Vgs(th) (Max) @ Id: 2.3V @ 250µA
  • Gate Charge (Qg) (Max) @ Vgs: 88nC @ 4.5V
  • Supplier Device Package: 22-VSON-CLIP (5x6)
  • Mounting Type: Surface Mount
  • Base Part Number: CSD88584
  • detail: Mosfet Array 2 N-Channel (Half Bridge) 40V 12W Surface Mount 22-VSON-CLIP (5x6)
