T3035H-8I Datasheet
Datasheet specifications
| Datasheet's name | T3035H-8I |
|---|---|
| File size | 60.145 KB |
| File type | |
| Number of pages | 11 |
Download Datasheet T3035H-8I |
Download Datasheet |
|---|
Other documentations
T3035H-8I 11 pages
T3035H-8I Datasheet 11 pages
Technical specifications
- RoHS: true
- Category: Triode/MOS Tube/Transistor/TRIACs
- Datasheet: STMicroelectronics T3035H-8I
- Package: TO-220AB-3
- Manufacturer: STMicroelectronics
- Series: Snubberless™
- Packaging: Tube
- Part Status: Active
- Triac Type: Alternistor - Snubberless
- Voltage - Off State: 800V
- Current - On State (It (RMS)) (Max): 30A
- Voltage - Gate Trigger (Vgt) (Max): 1.3V
- Current - Non Rep. Surge 50, 60Hz (Itsm): 283A, 270A
- Current - Gate Trigger (Igt) (Max): 35mA
- Current - Hold (Ih) (Max): 60mA
- Configuration: Single
- Operating Temperature: -40°C ~ 150°C (TJ)
- Mounting Type: Through Hole
- Package / Case: TO-220-3
- Supplier Device Package: TO-220AB Insulated
- Base Part Number: T3035
- detail: TRIAC Alternistor - Snubberless 800V 30A Through Hole TO-220AB Insulated
