- دیتاشیت CC2652R1FRGZT
CC2652R1FRGZT دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | CC2652R1FRGZT |
|---|---|
| حجم فایل | 88.606 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 68 |
دانلود دیتاشیت CC2652R1FRGZT |
دانلود دیتاشیت |
|---|
سایر مستندات
CC2652R 70 pages
CC2652R1FRGZT 47 pages
مشخصات فنی
- RoHS: true
- Category: Radio Frequency Chip/Antenna/RF Transceiver ICs
- Data Rate: 2Mbps
- Datasheet: Texas Instruments CC2652R1FRGZT
- Interface: ADC,GPIO,I2C,I2S,JTAG,SPI,UART
- Applications: 802.15.4,Bluetooth
- Frequency Range: 2.4GHz~2.48GHz
- Receive Current: 6.9mA
- Operating Voltage: 1.8V~3.8V
- Operating Temperature: -40°C~+85°C
- Current Of Transmitting: 7.3mA
- Package: QFN-48-EP(7x7)
- Manufacturer: Texas Instruments
- Current - Transmitting: 7.3mA ~ 9.6mA
- Voltage - Supply: 1.8V ~ 3.8V
- Data Rate (Max): 2Mbps
- Packaging: Cut Tape (CT)
- Type: TxRx + MCU
- Sensitivity: -105dBm
- GPIO: 31
- Part Status: Active
- Protocol: Bluetooth v5.1, Thread, Zigbee®
- Supplier Device Package: 48-VQFN (7x7)
- Modulation: DSSS, O-QPSK
- RF Family/Standard: 802.15.4, Bluetooth
- Frequency: 2.4GHz ~ 2.48GHz
- Serial Interfaces: ADC, GPIO, I²C, I²S, JTAG, SPI, UART
- Current - Receiving: 6.9mA
- Package / Case: 48-VFQFN Exposed Pad
- Power - Output: 5dBm
- Mounting Type: Surface Mount
- Memory Size: 352kB Flash, 80kB RAM
- Base Part Number: CC2652
- Series: SimpleLink™
- detail: IC RF TxRx + MCU 802.15.4, Bluetooth Bluetooth v5.1, Thread, Zigbee® 2.4GHz ~ 2.48GHz 48-VFQFN Exposed Pad
