RoHS: true
Category: Power Supply Chip/Linear Voltage Regulators (LDO)
Datasheet: Texas Instruments TPS7A8300ARGWT
Package: QFN-20-EP(5x5)
Manufacturer: Texas Instruments
Current - Supply (Max): 5mA
Output Configuration: Positive
Package / Case: 20-VQFN Exposed Pad
Packaging: Cut Tape (CT)
Protection Features: Over Current, Over Temperature, Under Voltage Lockout (UVLO)
Number of Regulators: 1
Part Status: Active
Current - Quiescent (Iq): 4mA
Operating Temperature: -40°C ~ 125°C (TJ)
Supplier Device Package: 20-VQFN (5x5)
Voltage - Input (Max): 6.5V
Voltage - Output (Min/Fixed): 0.8V
Mounting Type: Surface Mount
PSRR: 42dB ~ 25dB (10kHz ~ 500kHz)
Base Part Number: TPS7A8
Series: -
Output Type: Adjustable/Programmable
Control Features: Enable, Power Good, Soft Start
Voltage - Output (Max): 5.2V
Voltage Dropout (Max): 0.3V @ 2A
Current - Output: 2A
detail: Linear Voltage Regulator IC 1 Output 2A 20-VQFN (5x5)
