دیتاشیت TPS54540BQDDAQ1
مشخصات دیتاشیت
| نام دیتاشیت | TPS54540B-Q1 Datasheet |
|---|---|
| حجم فایل | 2722.242 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 45 |
دانلود دیتاشیت TPS54540B-Q1 Datasheet |
TPS54540B-Q1 Datasheet Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Power Supply Chip/DC-DC Converters
- Function: Step-down type
- Topology: Step-down
- Datasheet: Texas Instruments TPS54540BQDDAQ1
- Output Type: Adjustable
- Input Voltage: 4.5V~42V
- Output Voltage: 0.8V~41.1V
- Number of Outputs: 1
- Switching Frequency: 2.5MHz
- Output Current (Max): 5A
- Operating Temperature: -40°C~+125°C@(TA)
- Synchronous Rectification: NO
- Package: SO-8
- Manufacturer: Texas Instruments
- Current - Output: 5A
- Voltage - Input (Max): 42V
- Frequency - Switching: 100kHz ~ 2.5MHz
- Part Status: Active
- Base Part Number: TPS545
- Voltage - Output (Min/Fixed): 0.8V
- Package / Case: 8-PowerSOIC (0.154", 3.90mm Width)
- Series: Automotive, AEC-Q100
- Packaging: Tube
- Synchronous Rectifier: No
- Output Configuration: Positive
- Voltage - Output (Max): 41.1V
- Mounting Type: Surface Mount
- Supplier Device Package: 8-SO PowerPad
- Voltage - Input (Min): 4.5V
- detail: Buck, Split Rail Switching Regulator IC Positive Adjustable 0.8V 1 Output 5A 8-PowerSOIC (0.154", 3.90mm Width)
