TMS320F28075PTPT دیتاشیت

مشخصات دیتاشیت

دانلود دیتاشیت TMS320F28075PTPT	دانلود دیتاشیت

RoHS: true
CPU Core: Other series
Category: Single Chip Microcomputer/Microcontroller/Microcontroller Units (MCUs/MPUs/SOCs)
Watchdog: Yes
ADC (Bit): 12bit
DAC (Bit): 12bit
Datasheet: Texas Instruments TMS320F28075PTPT
CPU Maximum Speed: 120MHz
GPIO Ports Number: 97
Low-Voltage Detect: Yes
Direct Memory Access: Yes
Program Storage Size: 512KB
Universal Serial Bus: Yes
Operating Voltage Range: 1.14V~3.47V
Operating Temperature Range: -40°C~+105°C
Package: LQFP-176(24x24)
Manufacturer: Texas Instruments
Speed: 120MHz
Data Converters: A/D 17x12b; D/A 3x12b
Oscillator Type: External
Package / Case: 176-LQFP Exposed Pad
Packaging: Tray
Peripherals: DMA, POR, PWM, WDT
Part Status: Active
Supplier Device Package: 176-HLQFP (24x24)
RAM Size: 50K x 16
Program Memory Type: FLASH
Core Size: 32-Bit
Core Processor: C28x
Program Memory Size: 512KB (256K x 16)
Operating Temperature: -40°C ~ 105°C (TA)
Mounting Type: Surface Mount
Number of I/O: 97
Base Part Number: TMS320
Series: C2000™ C28x Piccolo™
EEPROM Size: -
Connectivity: CANbus, EBI/EMI, I²C, McBSP, SCI, SPI, UART/USART, USB
Voltage - Supply (Vcc/Vdd): 1.14V ~ 3.47V
detail: C28x C2000™ C28x Piccolo™ Microcontroller IC 32-Bit 120MHz 512KB (256K x 16) FLASH 176-HLQFP (24x24)
