- دیتاشیت TLC4541ID
TLC4541ID دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | TLC4541ID |
|---|---|
| حجم فایل | 94.242 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 29 |
دانلود دیتاشیت TLC4541ID |
دانلود دیتاشیت |
|---|
سایر مستندات
TLC4541, TLC4545 28 pages
مشخصات فنی
- RoHS: true
- Category: ADC/DAC/Data Conversion/Analog To Digital Converters (ADCs)
- Datasheet: Texas Instruments TLC4541ID
- Interface: SPI
- resolution: 16Bit
- Supply Voltage: 5V
- number of channels: 1
- sampling frequency: 200kHz
- Operating Temperature: -40°C~+85°C
- Package: SOP-8
- Manufacturer: Texas Instruments
- Architecture: SAR
- Input Type: Single Ended
- Series: -
- Ratio - S/H:ADC: 1:1
- Packaging: Tube
- Data Interface: SPI
- Reference Type: External
- Part Status: Active
- Supplier Device Package: 8-SOIC
- Number of A/D Converters: 1
- Sampling Rate (Per Second): 200k
- Configuration: S/H-ADC
- Package / Case: 8-SOIC (0.154", 3.90mm Width)
- Mounting Type: Surface Mount
- Base Part Number: TLC454
- Features: -
- Number of Bits: 16
- Number of Inputs: 1
- Voltage - Supply, Analog: 5V
- Voltage - Supply, Digital: 5V
- detail: 16 Bit Analog to Digital Converter 1 Input 1 SAR 8-SOIC
