TLC3548IPW دیتاشیت

TLC3548IPW

مشخصات دیتاشیت

نام دیتاشیت TLC3548IPW
حجم فایل 110.238 کیلوبایت
نوع فایل pdf
تعداد صفحات 50

دانلود دیتاشیت TLC3548IPW

دانلود دیتاشیت

سایر مستندات

TLC3544, TLC3548 35 pages

مشخصات فنی

  • RoHS: true
  • Category: ADC/DAC/Data Conversion/Analog To Digital Converters (ADCs)
  • Datasheet: Texas Instruments TLC3548IPW
  • Interface: SPI
  • resolution: 14Bit
  • Supply Voltage: 5V
  • number of channels: 4;8
  • sampling frequency: 200kHz
  • Operating Temperature: -40°C~+85°C
  • Package: TSSOP-24
  • Manufacturer: Texas Instruments
  • Architecture: SAR
  • Input Type: Pseudo-Differential, Single Ended
  • Series: -
  • Ratio - S/H:ADC: 1:1
  • Packaging: Tube
  • Data Interface: SPI
  • Reference Type: External, Internal
  • Part Status: Active
  • Supplier Device Package: 24-TSSOP
  • Number of A/D Converters: 1
  • Sampling Rate (Per Second): 200k
  • Configuration: MUX-S/H-ADC
  • Package / Case: 24-TSSOP (0.173", 4.40mm Width)
  • Mounting Type: Surface Mount
  • Base Part Number: TLC354
  • Features: -
  • Number of Bits: 14
  • Number of Inputs: 4, 8
  • Voltage - Supply, Analog: 5V
  • Voltage - Supply, Digital: 2.7V ~ 5.5V
  • detail: 14 Bit Analog to Digital Converter 4, 8 Input 1 SAR 24-TSSOP
