دیتاشیت LM120H-5.0

LM120/LM320

مشخصات دیتاشیت

نام دیتاشیت LM120/LM320
حجم فایل 1571 کیلوبایت
نوع فایل pdf
تعداد صفحات 22

دانلود دیتاشیت LM120/LM320

LM120/LM320 Datasheet

مشخصات

  • Manufacturer: Texas Instruments
  • Voltage - Input (Max): -25V
  • Current - Quiescent (Iq): 1mA
  • Output Configuration: Negative
  • Base Part Number: LM120
  • Voltage - Output (Min/Fixed): -5V
  • Protection Features: Over Temperature
  • Series: -
  • Packaging: Bulk
  • PSRR: 64dB (120Hz)
  • Supplier Device Package: TO-39-3
  • Package / Case: TO-205AD, TO-39-3 Metal Can
  • Number of Regulators: 1
  • Operating Temperature: -55°C ~ 150°C
  • Part Status: Active
  • Output Type: Fixed
  • Control Features: -
  • Voltage - Output (Max): -
  • Mounting Type: Through Hole
  • Voltage Dropout (Max): -
  • Current - Output: 1.5A
  • detail: Linear Voltage Regulator IC 1 Output 1.5A TO-39-3
