PTH05020WAH دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت PTH05020WAH	دانلود دیتاشیت

RoHS: true
Category: Power Supply Chip/Power Modules
Datasheet: Texas Instruments PTH05020WAH
Package: DIP-10
Manufacturer: Texas Instruments
Current - Output (Max): 22A
Applications: ITE (Commercial)
Size / Dimension: 1.50" L x 0.87" W x 0.35" H (38.1mm x 22.1mm x 8.9mm)
Voltage - Input (Max): 5.5V
Part Status: Active
Features: UVLO
Number of Outputs: 1
Packaging: Tray
Type: Non-Isolated PoL Module
Package / Case: 10-DIP Module
Efficiency: 95%
Voltage - Output 2: -
Series: PTH05020W
Operating Temperature: -40°C ~ 85°C
Base Part Number: PTH05
Voltage - Output 1: 0.8 ~ 3.6V
Mounting Type: Through Hole
Voltage - Output 3: -
Voltage - Input (Min): 4.5V
detail: Non-Isolated PoL Module DC DC Converter 1 Output 0.8 ~ 3.6V 22A 4.5V - 5.5V Input
