دیتاشیت SN74HC682N

SN54HC682, SN74HC682

مشخصات دیتاشیت

نام دیتاشیت SN54HC682, SN74HC682
حجم فایل 897.972 کیلوبایت
نوع فایل pdf
تعداد صفحات 14

دانلود دیتاشیت SN54HC682, SN74HC682

SN54HC682, SN74HC682 Datasheet

مشخصات

  • RoHS: true
  • Output: Active Low
  • Category: Logic ICs/Digital Comparators
  • Datasheet: Texas Instruments SN74HC682N
  • Sink Current: 5.2mA
  • Source Current: 5.2mA
  • Supply Voltage: 2V~6V
  • Output Function: A=B,A>B
  • Number of Channels: 8
  • Operating Temperature: -40°C~+85°C
  • Maximum Propagation Delay: 47ns@6V,50pF
  • Package: PDIP-20
  • Manufacturer: Texas Instruments
  • Voltage - Supply: 2V ~ 6V
  • Package / Case: 20-DIP (0.300", 7.62mm)
  • Packaging: Tube
  • Type: Magnitude Comparator
  • Base Part Number: SN74HC6
  • Part Status: Active
  • Current - Output High, Low: 5.2mA, 5.2mA
  • Series: 74HC
  • Number of Bits: 8
  • Supplier Device Package: 20-PDIP
  • Mounting Type: Through Hole
  • Max Propagation Delay @ V, Max CL: 47ns @ 6V, 50pF
  • detail: Magnitude Comparator Bit Active Low Output A=B, A>B 20-PDIP
