TL714CP دیتاشیت

TL714CP

مشخصات دیتاشیت

نام دیتاشیت TL714CP
حجم فایل 62.07 کیلوبایت
نوع فایل pdf
تعداد صفحات 12

مشاهده دیتاشیت TL714CP

دانلود دیتاشیت

سایر مستندات

TL714C 13 pages

مشخصات فنی

  • RoHS: true
  • Category: Operational Amplifier/Comparator/Comparators
  • Datasheet: Texas Instruments TL714CP
  • Output Type: Push Pull
  • Supply Current: 12mA
  • Supply Voltage: 4.75V~5.25V
  • Number of Elements: 1
  • Operating Temperature: 0°C~+70°C
  • Propagation Delay Time: 12ns
  • Input Bias Current (Ib): -
  • Input Offset Voltage (Vos): -
  • Input Hysteresis Voltage (Vhys): 30mV
  • Common Mode Rejection Ratio (CMRR): 70dB
  • Package: PDIP-8
  • Manufacturer: Texas Instruments
  • Package / Case: 8-DIP (0.300", 7.62mm)
  • Propagation Delay (Max): 12ns
  • Current - Quiescent (Max): 12mA
  • Voltage - Input Offset (Max): -
  • Part Status: Active
  • Current - Output (Typ): -
  • Current - Input Bias (Max): -
  • Packaging: Tube
  • Type: Differential
  • CMRR, PSRR (Typ): -
  • Voltage - Supply, Single/Dual (±): 4.75V ~ 5.25V
  • Series: -
  • Base Part Number: TL714
  • Supplier Device Package: 8-PDIP
  • Mounting Type: Through Hole
  • Hysteresis: 30mV
  • detail: Comparator Differential Push-Pull, TTL 8-PDIP
