DAC811JU دیتاشیت

DAC811JU

مشخصات دیتاشیت

نام دیتاشیت DAC811JU
حجم فایل 95.856 کیلوبایت
نوع فایل pdf
تعداد صفحات 13

مشاهده دیتاشیت DAC811JU

دانلود دیتاشیت

سایر مستندات

DAC811 14 pages

مشخصات فنی

  • RoHS: true
  • Category: ADC/DAC/Data Conversion/Digital To Analog Converters (DACs)
  • Datasheet: Texas Instruments DAC811JU
  • Interface: Parallel
  • Resolution: 12Bit
  • Output Type: Voltage-缓冲
  • Settling Time: 4us
  • Supply Voltage: 5V
  • Integral nonlinearity: ±0.25LSB;±0.5LSB
  • Operating Temperature: 0°C~+70°C
  • Package: SOP-28-300mil
  • Manufacturer: Texas Instruments
  • Mounting Type: Surface Mount
  • Architecture: R-2R
  • INL/DNL (LSB): ±0.25, ±0.5
  • Number of Bits: 12
  • Part Status: Active
  • Package / Case: 28-SOIC (0.295", 7.50mm Width)
  • Voltage - Supply, Digital: 5V
  • Packaging: Tube
  • Data Interface: Parallel
  • Reference Type: Internal
  • Series: -
  • Differential Output: No
  • Supplier Device Package: 28-SOIC
  • Number of D/A Converters: 1
  • Voltage - Supply, Analog: ±11.4V ~ 16.5V
  • Base Part Number: DAC811
  • detail: 12 Bit Digital to Analog Converter 1 28-SOIC
