BTB08-600TWRG 数据手册
其他文档
BT(A,B)08, T8xx Datasheet 21 pages
技术规格
- RoHS: true
- Category: Triode/MOS Tube/Transistor/TRIACs
- Datasheet: STMicroelectronics BTB08-600TWRG
- Package: TO-220AB-3
- Manufacturer: STMicroelectronics
- Series: -
- Packaging: Tube
- Part Status: Active
- Triac Type: Logic - Sensitive Gate
- Voltage - Off State: 600V
- Current - On State (It (RMS)) (Max): 8A
- Voltage - Gate Trigger (Vgt) (Max): 1.3V
- Current - Non Rep. Surge 50, 60Hz (Itsm): 80A, 84A
- Current - Gate Trigger (Igt) (Max): 5mA
- Current - Hold (Ih) (Max): 10mA
- Configuration: Single
- Operating Temperature: -40°C ~ 150°C (TJ)
- Mounting Type: Through Hole
- Package / Case: TO-220-3
- Supplier Device Package: TO-220AB
- Base Part Number: BTB08
- detail: TRIAC Logic - Sensitive Gate 600V 8A Through Hole TO-220AB
