VIPER38LD دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت VIPER38LD	دانلود دیتاشیت

VIPER38 30 pages

RoHS: true
Category: Power Supply Chip/AC-DC Controllers & Regulators
Topology: Flyback
Datasheet: STMicroelectronics VIPER38LD
Duty Cycle: 80%
Supply Voltage: 8.5V~23.5V
Output Isolation: Isolation
Breakdown Voltage: 800V
Switching Frequency: 60kHz
Operating Temperature: -40°C~+150°C@(Tj)
Package: SOP-16
Manufacturer: STMicroelectronics
Series: VIPer™ plus
Packaging: Tube
Part Status: Active
Internal Switch(s): Yes
Voltage - Breakdown: 800V
Voltage - Start Up: 14V
Voltage - Supply (Vcc/Vdd): 8.5V ~ 23.5V
Frequency - Switching: 60kHz
Power (Watts): 20W
Fault Protection: Current Limiting, Over Temperature, Over Voltage, Short Circuit
Control Features: -
Package / Case: 16-SOIC (0.154", 3.90mm Width)
Supplier Device Package: 16-SO
Mounting Type: Surface Mount
Base Part Number: VIPER38
detail: Converter Offline Flyback Topology 60kHz 16-SO
