دیتاشیت TYN612MRG
مشخصات دیتاشیت
| نام دیتاشیت |
TYN612M
|
| حجم فایل |
106.866
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
8
|
مشخصات
-
RoHS:
true
-
Category:
Triode/MOS Tube/Transistor/TRIACs
-
SCR Type:
1个单向可控硅
-
Datasheet:
STMicroelectronics TYN612MRG
-
Holding Current (Ih):
20mA
-
Operating Temperature:
-40°C~+125°C
-
Gate Trigger Current(Igt):
5mA
-
Gate Trigger Voltage (Vgt):
1.3V
-
RMS On-State Current(It (rms)):
12A
-
Peak Forward On?State Voltage (Vtm):
1.6V
-
Peak Repetitive Off?State Voltage (Vdrm):
600V
-
Package:
TO-220
-
Manufacturer:
STMicroelectronics
-
Series:
-
-
Packaging:
Tube
-
Part Status:
Active
-
Voltage - Off State:
600V
-
Voltage - Gate Trigger (Vgt) (Max):
1.3V
-
Current - Gate Trigger (Igt) (Max):
5mA
-
Voltage - On State (Vtm) (Max):
1.6V
-
Current - On State (It (AV)) (Max):
8A
-
Current - On State (It (RMS)) (Max):
12A
-
Current - Hold (Ih) (Max):
20mA
-
Current - Off State (Max):
10µA
-
Current - Non Rep. Surge 50, 60Hz (Itsm):
120A, 125A
-
Mounting Type:
Through Hole
-
Package / Case:
TO-220-3
-
Supplier Device Package:
TO-220AB
-
Base Part Number:
TYN612
-
detail:
SCR 600V 12A Standard Recovery Through Hole TO-220AB
