TN4015H-6T Datasheet
Datasheet specifications
| Datasheet's name | TN4015H-6T |
|---|---|
| File size | 402.567 KB |
| File type | |
| Number of pages | 9 |
Download Datasheet TN4015H-6T |
Download Datasheet |
|---|
Other documentations
Technical specifications
- Manufacturer: STMicroelectronics
- Series: -
- Packaging: Tube
- Part Status: Active
- Voltage - Off State: 600V
- Voltage - Gate Trigger (Vgt) (Max): 1.3V
- Current - Gate Trigger (Igt) (Max): 15mA
- Voltage - On State (Vtm) (Max): 1.6V
- Current - On State (It (AV)) (Max): 22A
- Current - On State (It (RMS)) (Max): 40A
- Current - Hold (Ih) (Max): 60mA
- Current - Non Rep. Surge 50, 60Hz (Itsm): 360A, 390A
- SCR Type: Standard Recovery
- Operating Temperature: -40°C ~ 150°C
- Mounting Type: Through Hole
- Package / Case: TO-220-3
- Supplier Device Package: TO-220AB
- Base Part Number: TN4015
- detail: SCR 600V 40A Standard Recovery Through Hole TO-220AB
