دیتاشیت BTA06-800BWRG

BTA06-800BWRG

مشخصات دیتاشیت

نام دیتاشیت BTA06-800BWRG
حجم فایل 77.647 کیلوبایت
نوع فایل pdf
تعداد صفحات 2

BTA06-800BWRG

دانلود دیتاشیت

سایر مستندات

SCRs, Triacs, AC Switches and A.S.D.™ 26 pages

BTA06, BTB06 Series 7 pages

BTA06-600BRG 7 pages

مشخصات فنی

  • RoHS: true
  • Category: Triode/MOS Tube/Transistor/TRIACs
  • SCR Type: Two-way thyristor
  • Datasheet: JSMSEMI BTA06-800BWRG
  • Holding Current (Ih): 50mA
  • Operating Temperature: -40°C~+125°C@(Tj)
  • Gate Trigger Current(Igt): 50mA
  • Gate Trigger Voltage (Vgt): 1.3V
  • RMS On-State Current(It (rms)): 6A
  • Peak Forward On?State Voltage (Vtm): 1.55V
  • Average Gate Power Dissipation (PG(AV)): 1W
  • Peak Repetitive Off?State Voltage (Vdrm): 600V
  • Peak non-repetitive surge current (Itsm@f): 60A@50Hz
  • Package: TO-220
  • Manufacturer: JSMSEMI
  • Series: Snubberless™
  • Packaging: Tube
  • Part Status: Active
  • Triac Type: Alternistor - Snubberless
  • Voltage - Off State: 800V
  • Current - On State (It (RMS)) (Max): 6A
  • Voltage - Gate Trigger (Vgt) (Max): 1.3V
  • Current - Non Rep. Surge 50, 60Hz (Itsm): 60A, 63A
  • Current - Gate Trigger (Igt) (Max): 50mA
  • Current - Hold (Ih) (Max): 50mA
  • Configuration: Single
  • Mounting Type: Through Hole
  • Package / Case: TO-220-3
  • Supplier Device Package: TO-220AB
  • Base Part Number: BTA06
  • detail: TRIAC Alternistor - Snubberless 800V 6A Through Hole TO-220AB
