دیتاشیت STTH8R04D

STTH8R04

مشخصات دیتاشیت

نام دیتاشیت STTH8R04
حجم فایل 576.355 کیلوبایت
نوع فایل pdf
تعداد صفحات 14

دانلود دیتاشیت STTH8R04

STTH8R04 Datasheet

مشخصات

  • RoHS: true
  • Category: Diodes/Diodes - Fast Recovery Rectifiers
  • Datasheet: STMicroelectronics STTH8R04D
  • Diode Configuration: Single
  • Reverse Voltage (Vr): 400V
  • Operating Temperature: -40°C~+175°C@(Tj)
  • Forward Voltage (Vf@If): 1.5V@8A
  • Reverse Leakage Current: 10uA@400V
  • Reverse Recovery Time (trr): 35ns
  • Average Rectified Current (Io): 8A
  • Package: ITO-220AC
  • Manufacturer: STMicroelectronics
  • Series: -
  • Packaging: Tube
  • Part Status: Active
  • Diode Type: Standard
  • Voltage - DC Reverse (Vr) (Max): 400V
  • Current - Average Rectified (Io): 8A
  • Voltage - Forward (Vf) (Max) @ If: 1.5V @ 8A
  • Speed: Fast Recovery =< 500ns, > 200mA (Io)
  • Current - Reverse Leakage @ Vr: 10µA @ 400V
  • Capacitance @ Vr, F: -
  • Mounting Type: Through Hole
  • Package / Case: TO-220-2
  • Supplier Device Package: TO-220AC
  • Operating Temperature - Junction: -40°C ~ 175°C
  • Base Part Number: STTH8R04
  • detail: Diode Standard 400V 8A Through Hole TO-220AC
