L9733XPTR Datasheet

L9733XPTR

Datasheet specifications

Datasheet's name L9733XPTR
File size 92.635 KB
File type pdf
Number of pages 35

Download Datasheet L9733XPTR

Download Datasheet

Other documentations

L9733 35 pages

Technical specifications

  • RoHS: true
  • Category: Power Supply Chip/Power Distribution Switches
  • Datasheet: STMicroelectronics L9733XPTR
  • Input Voltage: 4.5V~18V
  • Output Current: 1A
  • Number of Outputs: 8
  • Resistor On-State: 700mΩ
  • Operating Temperature -: -40°C~+125°C
  • Package: SSOP-28-300mil
  • Manufacturer: STMicroelectronics
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Switch Type: General Purpose
  • Ratio - Input:Output: 1:8
  • Output Configuration: High Side or Low Side
  • Output Type: N-Channel
  • Interface: SPI
  • Voltage - Load: 4.5V ~ 18V
  • Voltage - Supply (Vcc/Vdd): 4.5V ~ 5.5V
  • Current - Output (Max): 1A
  • Rds On (Typ): 700mOhm (Max)
  • Input Type: Non-Inverting
  • Features: PWM Input
  • Fault Protection: Open Load Detect, Over Temperature
  • Operating Temperature: -40°C ~ 125°C (TA)
  • Mounting Type: Surface Mount
  • Supplier Device Package: PowerSSO-28 Exposed Pad
  • Package / Case: 28-SSOP (0.295", 7.50mm Width) Exposed Pad
  • Base Part Number: L9733
  • detail: Power Switch/Driver 1:8 N-Channel 1A PowerSSO-28 Exposed Pad
