دیتاشیت STTH1212D

STTH1212

مشخصات دیتاشیت

نام دیتاشیت STTH1212
حجم فایل 123.9 کیلوبایت
نوع فایل pdf
تعداد صفحات 9

دانلود دیتاشیت STTH1212

STTH1212 Datasheet

مشخصات

  • RoHS: true
  • Category: Diodes/Diodes - Fast Recovery Rectifiers
  • Datasheet: STMicroelectronics STTH1212D
  • Reverse Voltage (Vr): 1.2kV
  • Operating Temperature: +175°C@(Tj)
  • Forward Voltage (Vf@If): 2.2V@12A
  • Reverse Leakage Current: 10uA@1.2kV
  • Reverse Recovery Time (trr): 100ns
  • Average Rectified Current (Io): 12A
  • Package: TO-220-2
  • Manufacturer: STMicroelectronics
  • Series: -
  • Packaging: Tube
  • Part Status: Active
  • Diode Type: Standard
  • Voltage - DC Reverse (Vr) (Max): 1200V
  • Current - Average Rectified (Io): 12A
  • Voltage - Forward (Vf) (Max) @ If: 2.2V @ 12A
  • Speed: Fast Recovery =< 500ns, > 200mA (Io)
  • Current - Reverse Leakage @ Vr: 10µA @ 1200V
  • Capacitance @ Vr, F: -
  • Mounting Type: Through Hole
  • Package / Case: TO-220-2
  • Supplier Device Package: TO-220AC
  • Operating Temperature - Junction: 175°C (Max)
  • Base Part Number: STTH1212
  • detail: Diode Standard 1200V 12A Through Hole TO-220AC
