دیتاشیت Diodes and Rectifiers Selection Guide

Diodes and Rectifiers Selection Guide

مشخصات دیتاشیت

نام دیتاشیت Diodes and Rectifiers Selection Guide
حجم فایل 834.654 کیلوبایت
نوع فایل pdf
تعداد صفحات 28

Diodes and Rectifiers Selection Guide

دانلود دیتاشیت

سایر مستندات

Protection Devices & Rectifiers Guide 16 pages

STTH15RQ06xY Datasheet 17 pages

مشخصات فنی

  • Manufacturer: STMicroelectronics
  • Series: Automotive, AEC-Q101
  • Packaging: Tube
  • Part Status: Active
  • Diode Type: Standard
  • Voltage - DC Reverse (Vr) (Max): 600V
  • Current - Average Rectified (Io): 15A
  • Voltage - Forward (Vf) (Max) @ If: 2.95V @ 15A
  • Speed: Fast Recovery =< 500ns, > 200mA (Io)
  • Reverse Recovery Time (trr): 50ns
  • Current - Reverse Leakage @ Vr: 20µA @ 600V
  • Capacitance @ Vr, F: -
  • Mounting Type: Through Hole
  • Package / Case: DO-247-2 (Straight Leads)
  • Supplier Device Package: DO-247
  • Operating Temperature - Junction: -40°C ~ 175°C
  • Base Part Number: STTH15R
  • detail: Diode Standard 600V 15A Through Hole DO-247
