SN74AHC574DWR دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
SN74AHC574DWR
|
|
حجم فایل
|
73.159
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
31
|
مشخصات فنی
-
RoHS:
true
-
Type:
D-Type
-
Series:
74AHC
-
Category:
Logic ICs/Flip Flops
-
Function:
Standard
-
Datasheet:
Texas Instruments SN74AHC574DWR
-
Output Type:
Tri-State;Non-Inverted
-
Sink Current:
8mA
-
Trigger Type:
上升沿
-
Source Current:
8mA
-
Supply Voltage:
2V~5.5V
-
Clock Frequency:
115MHz
-
Input Capacitance:
3pF
-
Quiescent Current (Iq):
4uA
-
Maximum Propagation Delay:
10.6ns@5V,50pF
-
Package:
SOP-20-300mil
-
Manufacturer:
Texas Instruments
-
Number of Elements:
1
-
Voltage - Supply:
2V ~ 5.5V
-
Operating Temperature:
-40°C ~ 85°C (TA)
-
Package / Case:
20-SOIC (0.295", 7.50mm Width)
-
Packaging:
Cut Tape (CT)
-
Supplier Device Package:
20-SOIC
-
Number of Bits per Element:
8
-
Current - Output High, Low:
8mA, 8mA
-
Part Status:
Active
-
Base Part Number:
SN74AHC5
-
Mounting Type:
Surface Mount
-
Current - Quiescent (Iq):
4µA
-
Max Propagation Delay @ V, Max CL:
10.6ns @ 5V, 50pF
-
detail:
Flip Flop 1 Element D-Type 8 Bit Positive Edge 20-SOIC (0.295", 7.50mm Width)
