دیتاشیت SN74LVC574ARGYR
مشخصات دیتاشیت
| نام دیتاشیت | SN54LVC574A, SN74LVC574A |
|---|---|
| حجم فایل | 2436.269 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 34 |
دانلود دیتاشیت SN54LVC574A, SN74LVC574A |
SN54LVC574A, SN74LVC574A Datasheet |
|---|
مشخصات
- Number of Elements: 1
- Trigger Type: Positive Edge
- Manufacturer: Texas Instruments
- Voltage - Supply: 1.65V ~ 3.6V
- Series: 74LVC
- Operating Temperature: -40°C ~ 85°C (TA)
- Package / Case: 20-VFQFN Exposed Pad
- Function: Standard
- Packaging: Cut Tape (CT)
- Type: D-Type
- Supplier Device Package: 20-VQFN (3.5x4.5)
- Clock Frequency: 150MHz
- Number of Bits per Element: 8
- Current - Output High, Low: 24mA, 24mA
- Part Status: Active
- Output Type: Tri-State, Non-Inverted
- Base Part Number: SN74LVC57
- Input Capacitance: 4pF
- Mounting Type: Surface Mount
- Current - Quiescent (Iq): 1.5µA
- Max Propagation Delay @ V, Max CL: 6.8ns @ 3.3V, 50pF
- detail: Flip Flop 1 Element D-Type 8 Bit Positive Edge 20-VFQFN Exposed Pad
