Power Management Guide دیتاشیت

Power Management Guide

مشخصات دیتاشیت

نام دیتاشیت Power Management Guide
حجم فایل 6420.273 کیلوبایت
نوع فایل pdf
تعداد صفحات 93

دانلود دیتاشیت Power Management Guide

دانلود دیتاشیت

سایر مستندات

LP5907 Datasheet 47 pages

LDOs Quick Reference Guide 6 pages

LP5907SNX-2.8/NOPB 46 pages

مشخصات فنی

  • RoHS: true
  • Category: Power Supply Chip/Linear Voltage Regulators (LDO)
  • Datasheet: Texas Instruments LP5907UVX-3.2/NOPB
  • Output Current: 250mA
  • Output Voltage: 3.2V
  • Dropout Voltage: 0.2V@(250mA)
  • Output Polarity: positive
  • Number of Outputs: 1
  • Maximum Input Voltage: 5.5V
  • Operating Temperature: -40°C~+125°C
  • Quiescent Current (Ground Current): 25uA
  • Package: BGA-4
  • Manufacturer: Texas Instruments
  • Voltage - Input (Max): 5.5V
  • Current - Quiescent (Iq): 25µA
  • Output Configuration: Positive
  • Base Part Number: LP5907
  • Voltage - Output (Min/Fixed): 3.2V
  • Protection Features: Over Temperature, Short Circuit
  • Series: -
  • Packaging: Cut Tape (CT)
  • PSRR: 90dB ~ 60dB (100Hz ~ 100kHz)
  • Supplier Device Package: 4-DSBGA
  • Package / Case: 4-XFBGA, DSBGA
  • Number of Regulators: 1
  • Part Status: Active
  • Output Type: Fixed
  • Control Features: Enable
  • Voltage - Output (Max): -
  • Mounting Type: Surface Mount
  • Voltage Dropout (Max): 0.2V @ 250mA
  • Current - Output: 250mA
  • detail: Linear Voltage Regulator IC 1 Output 250mA 4-DSBGA
