LM193,293,393(A), 2903(V) Datasheet Datasheet

LM193,293,393(A), 2903(V) Datasheet

Datasheet specifications

Datasheet's name LM193,293,393(A), 2903(V) Datasheet
File size 2085.732 KB
File type pdf
Number of pages 45

Download Datasheet LM193,293,393(A), 2903(V) Datasheet

Download Datasheet

Other documentations

LM393PE4 55 pages

Technical specifications

  • RoHS: true
  • Category: Operational Amplifier/Comparator/Comparators
  • Datasheet: Texas Instruments LM2903DRG3
  • Output Type: 互补;Push Pull
  • Supply Voltage: 2V~36V;1V~18V
  • Number of Elements: -
  • Operating Temperature: -40°C~+125°C
  • Input Bias Current (Ib): 0.25uA
  • Input Offset Voltage (Vos): 7mV
  • Input Hysteresis Voltage (Vhys): -
  • Common Mode Rejection Ratio (CMRR): 100dB
  • Package: SOP-8
  • Manufacturer: Texas Instruments
  • Package / Case: 8-SOIC (0.154", 3.90mm Width)
  • Propagation Delay (Max): -
  • Current - Quiescent (Max): 2.5mA
  • Voltage - Input Offset (Max): 7mV @ 30V
  • Part Status: Active
  • Current - Output (Typ): 20mA
  • Current - Input Bias (Max): 0.25µA @ 5V
  • Packaging: Cut Tape (CT)
  • Type: Differential
  • CMRR, PSRR (Typ): -
  • Voltage - Supply, Single/Dual (±): 2V ~ 36V, ±1V ~ 18V
  • Series: -
  • Base Part Number: LM2903
  • Supplier Device Package: 8-SOIC
  • Mounting Type: Surface Mount
  • Hysteresis: -
  • detail: Comparator Differential CMOS, MOS, Open-Drain, TTL 8-SOIC
