LM158,258,358(A),2904(V) Datasheet Datasheet

LM158,258,358(A),2904(V) Datasheet

Datasheet specifications

Datasheet's name LM158,258,358(A),2904(V) Datasheet
File size 3380.794 KB
File type pdf
Number of pages 56

Download Datasheet LM158,258,358(A),2904(V) Datasheet

Download Datasheet

Other documentations

LM2904VQPWR 65 pages

Technical specifications

  • RoHS: true
  • Category: Operational Amplifier/Comparator/Operational Amplifier
  • Datasheet: Texas Instruments LM358DRG3
  • -3db Bandwidth: -
  • Output Current: 40mA
  • Operating Temperature: 0°C~+70°C
  • Current - Input Bias(Ib): 20nA
  • Gain Bandwidth Product(GBP): 700kHz
  • Package: SOP-8
  • Manufacturer: Texas Instruments
  • Current - Output / Channel: 30mA
  • Slew Rate: 0.3V/µs
  • Voltage - Input Offset: 3mV
  • Part Status: Active
  • Number of Circuits: 2
  • Packaging: Cut Tape (CT)
  • Supplier Device Package: 8-SOIC
  • Package / Case: 8-SOIC (0.154", 3.90mm Width)
  • Voltage - Supply, Single/Dual (±): 3V ~ 32V, ±1.5V ~ 16V
  • Series: -
  • Output Type: -
  • Base Part Number: LM358
  • Current - Supply: 1mA
  • Mounting Type: Surface Mount
  • Amplifier Type: General Purpose
  • Current - Input Bias: 20nA
  • Gain Bandwidth Product: 700kHz
  • detail: General Purpose Amplifier 2 Circuit 8-SOIC
