دیتاشیت TLV7162818PDPQR
مشخصات دیتاشیت
| نام دیتاشیت | TLV7162818PDPQR |
|---|---|
| حجم فایل | 70.999 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 25 |
TLV7162818PDPQR |
دانلود دیتاشیت |
|---|
سایر مستندات
TLV716(P) Datasheet 24 pages
مشخصات فنی
- RoHS: true
- Category: Power Supply Chip/Linear Voltage Regulators (LDO)
- Datasheet: Texas Instruments TLV7162818PDPQR
- Output Current: 150mA
- Output Voltage: 2.8V;1.8V
- Dropout Voltage: 0.45V@(150mA);0.9V@(150mA)
- Output Polarity: positive
- Number of Outputs: 2
- Maximum Input Voltage: 5.5V
- Operating Temperature: -40°C~+125°C@(Tj)
- Quiescent Current (Ground Current): 75uA
- Package: X2-SON-6
- Manufacturer: Texas Instruments
- Voltage - Input (Max): 5.5V
- Current - Quiescent (Iq): 75µA
- Output Configuration: Positive
- Base Part Number: TLV716
- Voltage - Output (Min/Fixed): 2.8V, 1.8V
- Protection Features: Over Current, Over Temperature, Reverse Polarity, Short Circuit, Under Voltage Lockout (UVLO)
- Series: -
- Packaging: Cut Tape (CT)
- PSRR: 80dB ~ 46dB (100Hz ~ 10kHz)
- Supplier Device Package: 6-X2SON (1.2x1.2)
- Package / Case: 6-XFDFN Exposed Pad
- Number of Regulators: 2
- Part Status: Active
- Output Type: Fixed
- Control Features: Enable
- Voltage - Output (Max): -
- Mounting Type: Surface Mount
- Voltage Dropout (Max): 0.45V @ 150mA, 0.9V @ 150mA
- Current - Output: 150mA
- detail: Linear Voltage Regulator IC 2 Output 150mA 6-X2SON (1.2x1.2)
