TPS22970YZPT دیتاشیت

TPS22970YZPT

مشخصات دیتاشیت

نام دیتاشیت TPS22970YZPT
حجم فایل 93.329 کیلوبایت
نوع فایل pdf
تعداد صفحات 25

دانلود دیتاشیت TPS22970YZPT

دانلود دیتاشیت

سایر مستندات

TPS22970 Datasheet 25 pages

مشخصات فنی

  • RoHS: true
  • Category: Power Supply Chip/Power Distribution Switches
  • Datasheet: Texas Instruments TPS22970YZPT
  • Input Voltage: 0.65V~3.6V
  • Output Current: 4A
  • Number of Outputs: 1
  • Resistor On-State: 4.7mΩ
  • Operating Temperature -: -40°C~+105°C
  • Package: BGA-8
  • Manufacturer: Texas Instruments
  • Input Type: Non-Inverting
  • Output Configuration: High Side
  • Operating Temperature: -40°C ~ 105°C (TA)
  • Packaging: Cut Tape (CT)
  • Ratio - Input:Output: 1:1
  • Switch Type: General Purpose
  • Part Status: Active
  • Supplier Device Package: 8-DSBGA
  • Mounting Type: Surface Mount
  • Fault Protection: -
  • Rds On (Typ): 4.7mOhm
  • Current - Output (Max): 4A
  • Package / Case: 8-XFBGA, DSBGA
  • Series: -
  • Interface: On/Off
  • Base Part Number: TPS229
  • Features: Slew Rate Controlled
  • Output Type: N-Channel
  • Voltage - Supply (Vcc/Vdd): -
  • Voltage - Load: 0.65V ~ 3.6V
  • detail: Power Switch/Driver 1:1 N-Channel 4A 8-DSBGA
