TL5001ACDR دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
TL5001ACDR
|
|
حجم فایل
|
111.581
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
32
|
مشخصات فنی
-
RoHS:
true
-
Category:
Power Supply Chip/DC-DC Controllers
-
Function:
boost converterType;Step-down type;Buck-boost type
-
Topology:
Step-down;Boost;Flyback
-
Datasheet:
Texas Instruments TL5001ACDR
-
Input Voltage:
3.6V~40V
-
Duty Cycle (Max):
100%
-
Number of Outputs:
1
-
Switching Frequency:
500kHz
-
Output Current (Max):
20mA
-
Operating Temperature:
-20°C~+85°C@(TA)
-
Synchronous Rectification:
NO
-
Package:
SOP-8
-
Manufacturer:
Texas Instruments
-
Part Status:
Active
-
Package / Case:
8-SOIC (0.154", 3.90mm Width)
-
Packaging:
Cut Tape (CT)
-
Frequency - Switching:
20kHz ~ 500kHz
-
Supplier Device Package:
8-SOIC
-
Serial Interfaces:
-
-
Synchronous Rectifier:
No
-
Clock Sync:
No
-
Mounting Type:
Surface Mount
-
Output Configuration:
Positive
-
Base Part Number:
TL500
-
Series:
-
-
Output Type:
Transistor Driver
-
Control Features:
Dead Time Control, Frequency Control
-
Output Phases:
1
-
Voltage - Supply (Vcc/Vdd):
3.6V ~ 40V
-
detail:
Buck, Boost, Flyback Regulator Positive Output Step-Up, Step-Down, Step-Up/Step-Down DC-DC Controller IC 8-SOIC
