SN74F174AN دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
SN74F174AN
|
|
حجم فایل
|
64.146
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
12
|
مشخصات فنی
-
RoHS:
true
-
Type:
D-Type
-
Series:
74F
-
Category:
Logic ICs/Flip Flops
-
Function:
Reset
-
Datasheet:
Texas Instruments SN74F174AN
-
Output Type:
Non-Inverted
-
Sink Current:
20mA
-
Trigger Type:
上升沿
-
Source Current:
1mA
-
Supply Voltage:
4.5V~5.5V
-
Clock Frequency:
140MHz
-
Number of Elements:
1
-
Operating Temperature:
0°C~+70°C
-
Quiescent Current (Iq):
45mA
-
Maximum Propagation Delay:
10ns@5V,50pF
-
Number of Bits per Element:
6
-
Package:
PDIP-16
-
Manufacturer:
Texas Instruments
-
Voltage - Supply:
4.5V ~ 5.5V
-
Package / Case:
16-DIP (0.300", 7.62mm)
-
Packaging:
Tube
-
Current - Output High, Low:
1mA, 20mA
-
Part Status:
Active
-
Base Part Number:
SN74F17
-
Supplier Device Package:
16-PDIP
-
Mounting Type:
Through Hole
-
Current - Quiescent (Iq):
45mA
-
Max Propagation Delay @ V, Max CL:
10ns @ 5V, 50pF
-
detail:
Flip Flop 1 Element D-Type 6 Bit Positive Edge 16-DIP (0.300", 7.62mm)
